MiiCraft Prime Series
MiiCraft Prime Series 3D Printers are advanced desktop 3D printers with super high resolution performance. This printer is powered by a true 4M pixel UV light engine. With dedicated image optimization technology and low force peeling mechanism, this printer is the best solution for highly accurate and detailed printing objects.
MiiCraft Prime
- Using industrial Grade Superior UV Optics & Light engine
- Unlimited choice of photopolymer resins, open material system
- UV curing wavelength choice: 385nm, 405nm
- Entire layer exposure, fast printing speed (>4cm/hour)
MiiCraft Prime & Ultra Series Comparison
Prime series utilizes superior high resolution UV light engine (4.1M pixels) realize stunning printing details.
| Item | Prime 150 | Prime 110 |
|---|---|---|
| Area(mm) | 150x84.5x120 | 110x62x120 |
| XY Res. | 55 μm | 40 μm |
| Z-Layer Resolution | 5 μm to 500 μm | |
| Wavelength(LED) | 385/405 nm wavelength are available for all configurations | |
| UI & Connectivity | Touch screen / Ethernet, USB | |
| Software | Operating System: Windows7, Windows8, Windows10 Network Browser: Google Chrome File input: .SLC, .STL File input size limitation: (1) Upload file from Computer, file limitation 500MB (2) Upload file from USB, file limitation 1G |
|
| Power Input | Printer: 19V DC / 4.73A With Adapter: 100~240V AC, 1.5A, 50Hz/60Hz |
|
| Operating Enviornment | Temperature: 10° to 30° Humidity (RH): 40% to 60% |
|
| Printer dimension W x D x H (cm) |
50 x 57 x 59 cm / 56 kilogram | |
| Package size and weight W x D x H (cm) |
80 x 80 x 93 cm / 76 kilogram | |
Accessories
Build Platform
Putty Knife
Resin tank / Premium Resin tank-Long life
Applications
Dental
Jewelry
Hearing Aid
Medical
Engineering
Manufacturing
Microfluidics
